Technical features
Single Air
| Flanges | 1 |
|---|---|
| Flange Length (mm) | 23 |
| Flange Inside Diameter Ø1 (mm) | 43 |
| Base Outside Diameter Ø2 (mm) | 86 |
| Height – H2 (mm) | 150 |
| Height – H1 (mm) | 127 |
| Top Outside Diameter Ø3 (mm) | 87 |
| Top material – Finish | Polyurethane |
Filter Material – Oiled Cotton Gauze
Flange Type – Inclined
Top style – Single Air
Flange Angle – 10°
Washable – Yes
Warranty – 2 Years Limited
